Fans & Blowers
Designed, built and installed under technical cooperation with Murakami Mfg. of Japan.
Applications
Boilers, dust collectors, incinerators, air conditioning, ventilation and chemical plants. We build centrifugal fans, multi-blade fans, single-stage and multistage blowers, and special fans.
- MVW-BD
- Single inlet, direct-coupledNo. 3 to No. 12
- MVW-CDB
- Double inlet, direct-coupledNo. 7.5 to No. 18
- Air flow range
- See catalogs
- Pressure range
- See catalogs
Catalogs include selection charts for 50/60 Hz and 4P/6P/8P motors. Performance based on 20 °C, 760 mmHg, 65% RH, gas density 1.2 kg/m³.
Features
Features
- Low vibration and noiseSmooth, quiet operation.
- Efficient impellersBlades developed over many years keep efficiency high across the flow range.
- Easy installationMotor and bearings precision-machined on a common centerline.
- Continuous dutyBearings designed for long service life.
- Dynamically balancedImpellers balanced on a NAGAHAMA-SCHENCK balancing machine.
Include in your inquiry
- Air flow and pressure
- Gas type and density
- Fan type, if specified
- Solids in the gas: amount and type
- Outlet direction and installation site
- Motor voltage, frequency, poles and type
- Flow control method
- 24-hour continuous operation or not
- Paint color
- Special material requirements
Accessories
Inlet vane dampers, discharge dampers, damper actuators, inlet silencers with filters.
Catalogs
- MVW-BD Single Inlet Fan Catalog (Chinese)PDF · 4.2 MB
- MVW-CDB Double Inlet Fan Catalog (Chinese)PDF · 4.8 MB
Need a quote or technical advice?
Send us your application, capacity, working pressure and fuel. We will recommend a model and quote.
